An Introduction to Siemens Step 7 5.x Maintenance
Learn how to navigate your way around the software in a very short amount of time. This series is focused on learning the fundamentals of STEP 7 5.x for S7-300/400 PLCs from a maintenance point of view.
As a long-standing, nationally recognized Siemens distributor, GCG brings over 30 years of expertise supporting manufacturers across 17 states. Our team of highly skilled engineers is dedicated to helping you improve productivity and achieve rapid ROI through smarter automation strategies. Backed by deep product knowledge and real-world experience, we provide tailored support for Siemens’ full range of industrial solutions, including automation systems, drives, motion control, industrial controls, power distribution, machine safety, and robotics.
Siemens Step 7 v5.x
Classic Engineering Software for SIMATIC S7-300/400 PLCs
Siemens STEP 7 V5.x is a legacy engineering software used for programming, configuring, and diagnosing Siemens SIMATIC S7-300 and S7-400 PLC systems. As part of the Totally Integrated Automation (TIA) ecosystem, STEP 7 V5.x provides a familiar interface and robust toolset for engineers working with traditional automation systems.
Reliable Support for Legacy Systems
Ensures continued programming and maintenance capabilities for long-established S7-300/400 PLC installations.
Comprehensive Programming Tools
Offers ladder logic (LAD), function block diagram (FBD), and statement list (STL) for flexible control strategy development.
Integrated Diagnostics
Built-in troubleshooting tools help minimize downtime and speed up fault detection.
Smooth Integration with Classic Siemens Hardware
Seamlessly connects with PROFIBUS, MPI, and other standard Siemens interfaces for reliable system communication.
Training Courses
Lesson 1: Hardware Configuration
In this lesson you will learn the basics of HW Config (Hardware configuration editor).
Lesson 2: Set PG/PC Interface and Accessible Nodes
In this lesson you will learn how to configure communication between PG/PC and PLC for programming as well as displaying Accessible Nodes.
Lesson 3: Edit Ethernet Node Edit Ethernet Node
In this lesson you will learn how to use Edit Ethernet Node to edit Ethernet device parameters and reset device to Factory settings.
Lesson 4: Downloading and Uploading
In this lesson you will learn about downloading and uploading hardware configuration and software.
Lesson 5: CPU Memory Areas and Addressing
In this lesson you will learn about the CPU Memory Areas and Addressing of the different areas.
Lesson 6: Erase Memory Card and perform Memory Reset
In this lesson you will learn how to erase the memory card and perform a memory reset of the controller.
Lesson 7: Symbols
In this lesson you will learn how to work with Symbolic names in the Symbol table.
Lesson 8: Block Overview
In this you will learn about the different block types: Organization Blocks (OB), Function Blocks (FB), Functions (FC) and Data Blocks (DB).
Lesson 9: Program Status
In this lesson you will learn how to view program status.
Lesson 10: Variable Address Table VAT
In this lesson you will learn how to monitor and modify addresses with VAT table.
Lesson 11: Hardware Configuration Monitor Modify
In this lesson you will learn how to monitor and modify addresses from HW Config editor.
Lesson 12: Forcing
In this lesson you will learn how to force fixed values for addresses.
Lesson 13: Hardware Diagnostics
In this lesson you will learn how to display Hardware Diagnostics for troubleshooting.
Lesson 14: Reference Data
In this lesson you will learn how to display Reference data make it easier to debug and modify the user program.
Lesson 15: Comparing Blocks
In this lesson you will learn how to compare offline vs. online program and two offline programs.
Lesson 16: Archive and Retrieve
In this lesson you will learn how to backup and restore a project with Arching and Retrieve.
